ENVIROMAX UTILITY - U90 & U120
No. Description U90 & U120
1 Front panel 212336
2 Left side panel 212343
3 Right side panel 212344
4 Top panel 212337
5 Back Support 212338
6 Base 211874
7 Back support Bracket 210916
8 Right support Bracket 210915
9 Left Support Bracket 213012
10 Boiler Shell 110921
11 Insulation Jacket 110910
12 Hydrostat Operation Control 113026
13 Burner Gasket 3005787
14 Burner Flange 3006384
15 Burner Riello RDB2.2R 90’000btu. 412977
Burner Riello RDB2.2R 120’000btu. 412978
16 Air Hose. 111902
17 Flue Gas Analysis Blank. 110923
18 Condense Trap 110935
19 Condensate Hose 111537
17
13
12
3
4
5
6
7
8
9
10
2
1
11
14
16
15
18
19
1. Frame 2. Cone 3. Float
4. Screw Cap 5. Connector
1
2
3
4
5
