FireBird System Range - Page 14

4
FLUE SYSTEMS
12
Slimline Heat Hac
(
B.
)
(D.)
HEAT PAC - Concentric Flue Assembl
y
.
Please follow all instructions and Buildin
g
Re
g
ulation extracts supplied with boiler.
42.
(
A.
)
M8 Fibre Washer
G
asket Seal.
M8 Washer
Boiler
Use an M13 Spanner to secure the flue adaptor to the boiler.
Apply high temperature sealant to the inside of flue.
Push the flue pipe through the hole in the side panel and place firmly over flue adaptor.
Boiler
(
C.)
Boiler
Push cowl into flue
Fit Terminal Guard To Side Caseing
For Left Hand Flue option
rotate flue adaptor and swap
removable side panels.
Boiler
Push cowl into flue
Fit Terminal Guard To Side Caseing
Removable lid to access plumbing conections
