SPARE PARTS-BURNER
10-A Burner Parts Illustration
Riello RDB Burner
Riello RDB Burner Parts
No. Code Spare Parts Description
1 3008512 Gasket
2 3006384 Flange
3 3002433 Cup-Shaped Head
3 3002447 Cup-Shaped Head
4 3007513 Electrode Assembly
5 3006552 Electrode Bracket
6 3008642 Nozzle Holder
7 3008878 Kit Seals
8 3008643 Collar
9 3008794 High Voltage Lead
10 3005708 Fan
10 3008645 Fan
11 3008647 Air Damper Assembly
11 3008839 Air Damper Assembly
12 3008646 P.E. Cell
13 3008863 Lead
14 3007479 Capacitor 4uf
15 3007582 Needle Valve
16 3008651 Regulator
17 3000439 Pump Seal
18 3008654 Pump
19 3008653 Filter - O - Ring
20 3007162 O - Ring
21 3009068 Connector
22 3007672 Flexible Oil Line
23 3008644 Tube
24 3008876 Pressure Gauge
25 3000443 Joint
26 3008650 Motor
27 3008648 Coil
28 3008879 Cover
29 3008851 Lead Coil
30 3008652 Control Box 535RSE/LD
31 3008649 Projection
