10-D System Pluming Parts Description
10
SPARE PARTS-BOILER
ITEM COMPONENT 50-70 70-90 90-120 PART No.
No.
1 Automatic air vent 1 1 1 FC 03010
2 Thermostat Pocket 1 1 1 FC 03020
2a Filler Spring 1 1 1 FC 03020a
2b Locking Spring 1 1 1 FC 03020b
3 Safety Valve 1 1 1 FC 03040
4 Filling loop isolating valve 1 1 1 FC 03100
4a Filling loop hose 1 1 1
4b Filling loop check valve 1 1 1
5 Circulating Pump 1 1 1 FC 03102
6 10 Ltr. Pressure Vessel 50/70 1 FC 0306070
12Ltr. Pressure Vessel 70/90 1 FC 0306090
14 Ltr. Pressure Vessel 90/120 1 FC 0306012
7 Pump Valve 22mm 2 2 1 FC 03101
8 Pump Valve 28mm 1 FC 0310128
9 1/2”drain cock 1 1 1 FC 03103
10 1/4 M/Fm Check Valve 1 1 1 FC 03040CV
11 Pressure Gauge 1 1 1 FC 03134
11a Pressure Gauge Bracket 1 1 1 FC 03135
11b Pressure Gauge Nut 1 1 1 FC03136
12 Green Neon Light Indicator 1 1 1 FC03138
13 Red Neon Light Indicator 1 1 1 FC 03140
14 22mm to 28mm Copper 1 FC 032228
