FireBird System Range - Page 45

10-F Parts Description
Firebird System Range 50/70 - 70/90
10
SPARE PARTS-BOILER
43
ITEM COMPONENT PART No. Qty
No. per boiler
1 Side Panel L H Side FC03118L 1
2 Side Panel R H Side FC03118R 1
3 Dual Stat IM TLSC 542764 1
4 Top Panel SS03121R 1
4a Flue Trim Plate FC03122 1
4b Conventional Trim Plate FC03123 1
6 Front Panel SS03120 1
7 Baffle Door - Door (3) FC0310890 1
8 Baffles (Gas Baffle) FS90 - R-09 4
9 Burner Mounting Flange R.D.B. 3006384 1
10 Flue Elbow FS90 - L-30 1
11 Drip Tray FS90 - L-31 1
12 Burner RDB 1 70190 (3513200) 1
13 Snorkel 3”snorkel pipe & jubilee clip 1
14 Instrument Panel SS70 - LS-L-46 1
15 Viewing glass bracket FC 03110 1
15a Viewing glass FC 03111 1
15b Viewing glass gasket P70-L-45 1
16 Flue gas analysis cover FC 03113 1
16a Flue gas analysis cover gasket FC 03114 1
1 Side Panel L H Side FC03118L 1
2 Side Panel R H Side FC03118R 1
3 Dual Stat IM TLSC 542764 1
4 Top Panel SS03121R 1
4a Flue Trim Plate FC03122 1
4b Conventional Trim Plate FC03123 1
6 Front Panel SS03120 1
7 Baffle Door - Door (3) FC0310890 1
8 Baffles (Gas Baffle) FS90 - R-09 4
9 Burner Mounting Flange R.D.B. 3006384 1
10 Flue Elbow FS90 - L-30 1
11 Drip Tray FS90 - L-31 1
12 Burner RDB 1 70190 (3513200) 1
13 Snorkel 3”snorkel pipe & jubilee clip 1
14 Instrument Panel SS70 - LS-L-46 1
15 Viewing glass bracket FC 03110 1
15a Viewing glass FC 03111 1
15b Viewing glass gasket P70-L-45 1
16 Flue gas analysis cover FC 03113 1
16a Flue gas analysis cover gasket FC 03114 1
Firebird System Range 50/70 White Cased Model
Firebird System Range 70/90 White Cased Model
