3
Part Number 18166, G, 01/11/2022
Specifications
System Specifications
Operating Voltage: 9-32V DC
Quiescent Current Draw: 200mA @ 12V DC, 100mA @ 24V DC, 240mA @ 32V DC
Alarm Current Draw: 220mA @ 12V DC, 115mA @ 24V DC, 260mA @ 32V DC
Operating/Storage Temperature: 22°F (-6°C) to 158°F (70°C)
Relay Output: 500mA
Display Dimensions: 2.6” (67mm) x 2.6” (67mm) x 2.0” (51mm)
Control Module Dimensions: 7.29” (186mm) x 5.49” (140mm) x 1.39” (36mm)
NOTE
ABOVE CURRENT DRAWS PERTAIN ONLY TO THE DISPLAY AND MODULE UNIT. FULL SYSTEM
CURRENT DRAWS MUST ALSO ACCOUNT FOR EACH DETECTOR USED IN THE SYSTEM.
Operation of the FBD-MZ Fire Detection System
The FBD-MZ Detection System allows the monitoring of 4-12 zones of smoke and heat detectors.
Eight (8) detectors may be installed on each zone of the system. The system will monitor and
report an alarm both visually and audibly. The system also has 2 additional dry contact relay
outputs that can be used for additional notification.
