Page 3

General Information

Installation

≥ 0.3m/12”

0.5m/

20m - 50m/66-164ft= 1 Reflector

5 - 20m/16-66ft =

1Reflector + Short Range Mask

50 - 120m/164-394ft= 4 Reflectors

5m - 120m/

16-394ft

Position beam as high as possible, but with a

minimum distance of 0.3m/12” from Detector

and Reflector to ceiling.

For detectors approved to UL268 refer to

NFPA72 for installation guidance. In such

installations, it is advised that the maximum

distance of Detector and Reflector from the

ceiling must be 10% of the distance between

floor and ceiling

Ensure correct Reflector selected for the

appropriate distance

Mount Detector and Reflector directly

opposite each other

Do not mount Reflector onto reflective

surfaces

Do NOT position Detector where personnel

or objects can enter the beam path

Do NOT install the Detector or Reflector in

environments where condensation or icing are

likely to occur unless preventative measures

have been taken

All installations should comply with local

regulations

20”
