15
4 TECHNICAL DATA
4.1 TECHNICAL DATA UCBTG018_V1
UCBTG018_V1
TECHNICAL DATA (DIMEMSIONS)
Equipment dim.A Inches 42.52
Equipment dim.B Inches 32.68
Equipment dim.H1 Inches 42.53
Equipment dim.H Inches 37.21
Equipment dim.H2 Inches 67.92
Tank drain height H3 Inches 14.57
TECHNICAL DATA (FUNCTIONALITY)
Kettle diameter Inches 23.62
Pan dimension H Inches 11.42
Pan area Inches² 438
Overvall volume Gallons 22
Useful volume Gallons 18
Mixer speed rpm 7÷22
Mixer torque Nm 96
Mixer power kW 0.37
Temperature °F (°C) 68÷428 (20÷220)
TECHNICAL DATA (INSTALLATION)
Electric power kW 0.6
(E) Voltage/Input ** V (A) 2 PHASE 208V (2.8 A) ; 2 PHASE 220-240 V (2.5 A)
IPX IPX 4
Gas power BTU/HR 54,600
(G) Gas connection Ø" 1/2 " NPT
Water pressure (optional) PSI (kPa) 25-50 (170-345)
(A) Hot water inlet (optional) Ø" 1/2 "
(B) Cold water inlet (optional) Ø" 1/2 "
Sound level dbA < 75
TECHNICAL DATA (STORAGE/MOVEMENT)
Packaging dim.A Inches 48
Packaging dim.B Inches 39
Packaging dim.H Inches 50
Volume ft³ 53
Net weight lbs 529
Gross weight lbs 617
**Verify on rating plate .
