COOKING LAYOUT
36
14.2.1 COOKING ICONS (MEANING)
Left or central icon: main control (when the SETPOINT is reached, heating stops and the countdown of
the cooking time starts)
↓
↑
Right icon: secondary control (when the SETPOINT is reached,
the heating stops)
Name Icon Description
Temperature at bottom
Temperature in the pan
Δ Temperature between bottom and main temperature
