CLEANING AND CARE
04
-
UCBTG018_V1
-
DIMU
-
00
-
EN
71
c) Turn the vertical scraper towards the wall of the vessel.
d) Lower the vertical scraper until the tooth of the block is inserted on the vertical scraper.(see detail).
To disassembly the vertical scraper from the mixer, follow the instructions below:
a) Lift the spring until it releases with the tooth and simultaneously raise the vertical scraper .
b) Turn the vertical scraper towards the center of the vessel.
c) Extract the vertical scraper from the external arm.
For the cleaning of vertical scraper see "MIXER CLEANING" paragraph
