Understanding the Alarm LEDs and Horn Patterns
CONDITION HORN LEDs SMART BUTTON KEY
Standby condition Red and Blue blink Quick push activates False Alarm Control
TM
once per minute and a longer press also activates a
Push-to-Test sequence.
Low-battery #1 Horn beeps once Yellow light flashes 5 Quick press will eliminate the low-battery
per minute times per minute after signal for about 8 hours.
horn beeps
Low-battery #2 Horn beeps once Yellow light flashes 7 Smart Button inoperable.
per minute times per minute after Replace battery immediately.
horn beeps
Fault condition Horn beeps 2 times Yellow light flashes 2 Press and hold to check the alarm again.
per minute times per minute after Replace alarm if it remains in fault
horn beeps condition.
Local smoke Horn sounds 3 long Red-Yellow-Orange Quick press activates
is detected tones, then pauses, lights flash with horn False Alarm Control
TM
.
every 4 seconds
Local smoke condition Red light flashes 3 Quick press releases
is latched times and repeats the latched LED.
once per minute
Quick Quiet™ False Red light flashes 1
Alarm Control™ time every 10 seconds
is activated
Local CO is detected Horn sounds 4 short Blue light flashes 4 Quick press activates
tone pattern every times right after horn False Alarm Control
TM
..
5 seconds
Local CO condition Blue light flashes 4 Quick press erases the CO
is memorized times and repeats memory signal.
once per minute.
CO Reset is activated Blue light flashes 1
time every 10 seconds
14
