SPECIFICATIONS
Supply:
120V (min. 102, max. 132) 60 Hz
Table 1: AMBIENT TEMPERATURE LIMITS
Power Consumption: 12 VA (Operating)
Shipping Weight (Approx.): 2.2 lbs. (1.4kg)
Table 2: LOAD RATINGS
APPROVALS
Underwriters Laboratories Inc.
Recognized Components Guide MCCZ2
File MP1537
FM Approvals
FM7610
ORDERING INFORMATION
CONTROL:
M4RT1 120 VAC (min.102, max 132) Supply, 60 Hz.
FLAME DETECTORS:
69ND1-1000K4 12 inch flame rod, 1/2NPT connector
69ND1 -1000K6 18 inch flame rod, 1/2NPT connector
69ND1-1000K8 24 inch flame rod, 1/2NPT connector
MAXIMUM MINIMUM
Control 125F (52C) - 40F (- 40C)
Flame Rod
(Tip 2460 F)
1500F (816C) - 40F (- 40C)
Fireye Terminal Typical Load Maximum Rating & 120V 60 Hz
3 or 4
Individual or combined
Pilot valve(s)
Solenoid valve
Ignition Transformer
125 VA pilot duty (solenoid valve) plus
250 VA (Transformer)
5 Main Fuel Valve(s)
125 VA pilot duty (solenoid) or
25 VA pilot duty (solenoid) and
400 VA (opening) motorized
8 Motor or contactor
Motor normally energized and de-energized by the
operating control whose rating must be suitable. Termi-
nal 8 rated to de-energize 9.8 FLA, 58.8 LRA, on safety
lockout.
A Alarm 50 VA, pilot duty
Minimum load requirement = 100mA
