Control Panel
1
2
4-1 Data-Minder(Multi-Meter) – Push the
SELECT button to show the Voltage, Hertz and
running hours. If the low oil indicator is lit,
check the oil level.
3
4
5
7
Ground Terminal – Consult an electrician
for local grounding regulations.
120V, 30A Twist-Lock (NEMA L5-30R)
120V, 20A Duplex – (NEMA 5-20R) 20 Amp
of current may be drawn from this 120 Volt
receptacle.
1
2
3
4
5
6
7
6
120V, 30A RV (NEMA TT-30R)
Total power drawn from all receptacles must not exceed the name plate rating.
NOTE:
8
Outlet Cover - Protect the receptacles from
dust and debris.
8
A - Digital display
B - AC voltage indicator
C - Frequency indicator
D - Hour indicator
E - Low oil indicator
F - Select button
Engine Switch - Flip the switch to the
“ON”(l) position and pull the recoil starter
to start the generator. Turn to the “OFF”(O)
position to turn off the generator.
Maximum full load 30 Amp current may be
drawn from this 120 Volt receptacle.
Maximum full load 30 Amp current may be
drawn from this 120 Volt receptacle.
