1
2
3
4
5
6
7
8
9
10
11
2
4-1 Data-Minder(Multi-Meter) – Push the
SELECT button to show the Voltage, Hertz and
running hours. If the low oil indicator is lit,
check the oil level.
3
4
5
7
Ground Terminal – Consult an electrician
for local grounding regulations.
120V, 30A Twist-Lock (NEMA L5-30R)
120V, 20A Duplex – (NEMA 5-20R) 20 Amp
of current may be drawn from this 120 Volt
receptacle.
6
120V, 30A RV (NEMA TT-30R)
Battery Switch – Power the electric starter.
9
Outlet Cover - Protect the receptacles from
dust and debris.
10
11
Page 11
NOTE:
Total power drawn from all receptacles must not exceed the name plate rating.
Engine Start Switch – Used to start engine
from the starter motor(Electric start model
only). To start engine, press and hold the
switch in the “START”(ll) position, the
engine will crank and attempt to start. When
the engine starts, release the switch to the
“RUN”(l) position.
1
Control Panel
A - Digital display
B - AC voltage indicator
C - Frequency indicator
D - Hour indicator
E - Low oil indicator
F - Select button
English
Maximum full load 30 Amp current may be
drawn from this 120 Volt receptacle.
Maximum full load 30 Amp current may be
drawn from this 120 Volt receptacle.
8
