WHAT YOU WILL SEE AND HEAR WITH THIS ALARM
Under Nor
mal Operations
Hor
n:
Silent Power/Smoke LED: Constant Gr
een
CO LED: Off
When You Test the Alarm
Hor
n:
3 beeps, pause, 3 beeps
Power/Smoke LED: Flashes Red in sync with the hor
n pattern
CO LED: Off, followed by
Horn: 4 beeps, pause, 4 beeps
Power/Smoke LED: Off
CO LED: Flashes Red in sync with the horn pattern
If Battery Becomes Low or is Missing
Horn:
chirps once a minute
Power/Smoke LED: Flashes Green On for 2 seconds/Off for
2 seconds. Low Battery Latch is now engaged.
CO LED: Off
If Alarm is Not Operating Properly
Horn: Three rapid chirps every minute
Power/Smoke LED: Flashes approximately once a minute
CO LED: Off
Alarm Levels of CO are Detected
Horn: 4 beeps, pause, 4 beeps*
Power/Smoke LED: Off
CO LED: During Alarm: Flashes Red in sync with the horn pattern.
After Alarm: Flashes Red On for 2 seconds/Off for 2
seconds. CO Alarm Latch is now engaged.
*NOTE: If unit goes into CO alarm, the regular 4 beeps-brief pause
cycle will repeat for fifteen minutes. After fifteen minutes, the pause
will incr
ease to one minute.
Smoke is Detected
Horn:
3 beeps, pause, 3 beeps
Power/Smoke LED: During Alarm: Flashes Red in sync with the
hor
n patter
n. After Alarm: Flashes Red On for 2
seconds/Off for 2 seconds. Smoke Alarm Latch is now
engaged.
CO LED: Of
f
Smoke Alar
m is Silenced
Horn: Off
Power/Smoke LED: Flashes
Red
CO LED: Off
CO Alar
m is Silenced
Horn: Off
Power/Smoke LED: Off
CO LED: Flashes Red
6
REGULAR MAINTENANCE
Use only the r
eplacement batteries listed below. The unit may not
operate pr
operly with other batteries. Never use rechargeable
batteries since they may not pr
ovide a constant charge.
This unit has been designed to be as maintenance-free as possible, but
ther
e are a few simple things you must do to keep it working properly:
• Test it at least once a week.
• Clean the Smoke/CO Alarm at least once a month; gently vacuum
the outside of the Smoke/CO Alarm using your household vacuum’s
soft brush attachment. T
est the Smoke/CO Alarm. Never use water,
cleaners or solvents since they may damage the unit.
•
If the Smoke/CO Alarm becomes contaminated by excessive dirt,
dust and/or grime, and cannot be cleaned to avoid unwanted
alarms, r
eplace the unit immediately.
• Relocate the unit if it sounds frequent unwanted alarms. See “Where
This Alarm Should Not Be Installed” for details.
•
When the battery back-up becomes weak, the Alarm will “chirp”
about once a minute (the low battery war
ning). This warning should
last 7 days, but you should replace the battery immediately to
continue your pr
otection. The Low Battery Latch feature will be
engaged. The Gr
een Power/Smoke LED will flash On for 2 seconds/
Off for 2 seconds.
Choosing a r
eplacement battery:
Y
our Smoke/CO Alarm requires two “AA” Energizer E91 batteries.
These
batteries ar
e available at many local retail stores.
Actual battery service life depends on the Alarm and the environment
in which it is installed. All the batteries specified above ar
e acceptable
replacement batteries for this unit. Regardless of the manufacturer’s
suggested battery life,
you MUST replace the battery immediately
once the unit star
ts “chirping” (the “low battery warning”).
To replace the batteries (without removing Alarm from the ceiling
or wall):
1. Open the battery compartment.
2. Press tabs A and B as shown in the
diagram and remove each battery.
3. Insert the new batteries, making sure
they snap completely into the battery
compartment. Match the terminals on
the ends of the batteries with the
terminals on the unit.
4. Close the battery compartment, and
then test the unit by pressing the
Test/Silence button.
Type of Alarm
Carbon Monoxide (CO)
What You See and Hear
Horn:
4 beeps, pause, 4 beeps
Power/Smoke LED: Of
f
CO LED: Flashes Red
Smoke
Hor
n:
3 beeps, pause, 3 beeps
Power/Smoke LED: Flashes Red
CO LED: Off
IF YOUR SMOKE/CO ALARM SOUNDS
WHAT TO DO FIRST–
IDENTIFY THE TYPE OF ALARM SIGNAL
Continued...
WEEKLY TESTING
•
NEVER use an open flame of any kind to test this unit. Y
ou
might accidentally damage or set fir
e to the unit or to your
home. The built-in test switch accurately tests the unit’
s
operation as r
equired by Underwriters Laboratories, Inc. (UL).
NEVER use vehicle exhaust! Exhaust may cause per
manent
damage and voids your warranty.
•
If the Alarm ever fails to test properly, replace it immediately.
Products under warranty may be returned to the manufacturer
for r
eplacement. See “Limited Warranty” at the end of this
manual.
It is impor
tant to test this unit every week to make
sure it is working properly. Using the test button is
the recommended way to test this Smoke/CO Alarm.
Y
ou can test this Smoke/CO Alarm by
pr
essing and
holding the T
est/Silence button on the Alarm cover.
During testing, you will see and hear the following
sequence:
• The
Horn will sound 3 beeps, pause, 3 beeps. The Power/Smoke
LED
flashes Red and the CO LED will be Off.
• Next the
Horn will sound 4 beeps, pause, 4 beeps. The Power/
Smoke LED will be Of
f and the
CO LED flashes Red.
If the unit does not alar
m, make sure the batteries are correctly
installed, and test again. If the unit still does not alar
m, replace it
immediately.
