First Data FD200Ti - Getting to know the FD200 Ti; Port connections

Getting to know the FD200
Ti
Port connections
ThepicturesshowanFD200
Ti
terminal.Theportsontheback
oftheFD200
Ti
terminalenableyoutoaddperipheralssuchas
PINpadsandcontactlessreaders.
➔ Phone (blue)
Fordial-uptransactionsusingaphoneline.
➔ USB (gray) and Serial (green)
YoumayconnectadditionalperipheralstotheUSBorCOM
ports,suchastheFD-10orFD-10CPINPads,and/orthe
FD-30PINPadorVivopay
®
4500ContactlessReaders,and/or
MagTek
®
MiniMICRCheckReader.
➔ Ethernet (yellow)
ForInternettransactionsusingCableorDSL.
Note:ThisisaClassILEDproduct.Someperipheralsrequireaseparatepowersource.
BeforeconnectingaUSBdeviceorsimilardevice,removethepowercableconnector
fromtheterminal’spowerport.
ETHERNET PHONEUSBCOM
