RAIL MOUNTED PRIVACY SCREEN
ASSEMBLY INSTRUCTIONS
RANGE
1. Remove the nut and washer from each stando.
2. Place the screen onto the Cable Carrier aligning
the bolts in each stando with the holes in the
Cable Carrier top rail.
3. From the bottom side of the Cable Carrier
through the access hole replace the washer
and nut onto each stando bolt and tighten.
INSTRUCTION SHEET #2581INS
PART #1730538
ASSEMBLED BENCH KIT
W/ CABLE CARRIER
ATTACHING HARWARE
PRIVACY SCREEN W/ STANDOFFS
BOTTOM VIEW
ACCESS HOLE IN BOTTOM
OF CABLE CARRIER
