First Office HEIGHT ADJUSTABLE TABLE - Install Spanner Bars; Join Bench Assembly Halves

6. Insert spanner bars into cross tubes of one bench assembly
half with notch facing downward and secure with m10x25 set
screws. (See chart for Spanner Bar insertion depth)
7. Slide the other bench assembly half onto the spanner bars.
If no cable carrier needs installed tighten remaining set
screws and bench assembly is compelte. If cable carrier is to
be installed leave second bench assembly half loose for final
adjustament and refer to cable carrier installation guide.
SPANNER BARS
CROSS TUBES
CROSS TUBES
BENCH ASSEMBLY HALF
BENCH
SIZES
SPANNER
BAR DEPTH
54 12.75"
60 9.75"
66 6.75"
72 3.75
INSTRUCTION SHEET # 2576INS
2
CABLE CARRIER
