SV 6 - (-) Trigger Start INPUT: This setting allows for any PIC programmed with value 6 to be used as
a (-) negative Remote Start Trigger Start INPUT.
SV 7 - (-) Glow Plug INPUT: This setting allows for any PIC programmed with value 7 to be used as a
Glow Plug INPUT for diesel wait to start function.
SV 8 - (-) Disable ARM/Disarm/Start INPUT: This setting allows any PIC programmed with value 8
to be used as a (-) negative arm/disarm/start disable INPUT when controlling the CM through
analog arm/disarm/start inputs. (will disable the analog disarm input command if ground is
present on both disarm input wire and disarm disable input wire simultaneously)
SV 9 - (N/C) Trunk INPUT: This setting allows any PIC programmed with value 9 to be used as a
Normally Closed-circuit Trunk pin INPUT. The CM will consider the zone open when ground is
removed, or the circuit status changes from (-) ground to power. This can be used as a single
trunk zone input for security or remote start
SV 10 - (N/C) Key Sense INPUT: This setting allows any PIC programmed with value 10 to be used as a
Normally Closed-circuit Key Sense Input. The CM will consider the key to be in the key cylinder
if when ground is removed, or the circuit status changes from (-) ground to power. Keysense is
recommended when using the RFID Unlock feature, remote starting manual transmission vehicle,
or when using passive arming mode with security
SV 11 - (N/C) Hood Status: This setting allows any PIC programmed with value 11 to be used as a
normally closed-circuit hood pin INPUT. The CM will consider the zone open when ground is
removed, or the circuit status changes from (-) ground to power. This can be used as a single hood
zone input for security or remote start
SV 12 - (N/C) Door INPUT: This setting allows any PIC programmed with value 12 to be used as a
normally closed-circuit door pin INPUT. The CM will consider the zone open when ground is
removed, or the circuit status changes from (-) ground to power. This can be used as a
SINGLE (1) door zone input for security or remote start. It is also recommended when using
the RFID Unlock feature, or Turbo timer mode.
SV 13 - (-) Pre-Warn INPUT: This setting allows any PIC programmed with value 13 to be used as an
auxiliary sensor prewarn Input. Once Armed the CM will activate the prewarn chirps if this input
sees ground/negative input.
SV 14 - (-) Instant Trigger INPUT: This setting allows any PIC programmed with value 14 to be used
as an Auxiliary Sensor Instant Trigger Input. Once Armed the CM will activate the Instant
trigger, sounding the alarm, if this input sees ground/negative input.
SV 15 - (-) CM ARM INPUT: This setting allows any PIC programmed with value 15 to be used as a
Control Module ARM input which will arm the brain, activating lock/arm outputs if necessary.
SV 16 - (-) CM DISARM INPUT: This setting allows any PIC programmed with value 16 to be used as
a Control Module DISARM input which will Disarm the brain, activating unlock/disarm outputs
if necessary. Will also disarm the brain when its sounding or has been triggered.
SV 17 - IGN & Sensor Bypass INPUT: This setting allows any PIC programmed with value 17 to be
used to bypass the CMX ignition input and the alarm sensor inputs while armed if it is being
used with a factory Remote Start or added to another device. This input needs to see (-) on the
input to use it properly.
SV 18 - (-) AUX 1 Trigger INPUT: This setting allows any PIC programmed with value 18 to be used
to activate AUX1 output (timing output based on feature 4-01) with a Pulsed or latched
ground/negative source.
