General operation
Seite/Page 20 - Kaptitel/Chapter 2: General operation 10.5.17
2.6.2 The Automatic input:
With (-) characterized connection is connected to GND.
With (+) characterized connection is the input.
The input is connected through a resistance to 12 V (with 24 V-operated internally generated). If the two connections
are short circuited over a potential-free contact, then the input current flows.
To be considered for an electronic contact the low input current and the polarity is to be selected.
The high input current is to be selected for an electromechanical contact.
The input is debounced (delay time approx.1 s).
On the input an external voltages must not be set.
Fig. 2.6.2-1: Data
Fig. 2.6.2-2: Settings
Attention!The automatic adapter must only be used together with
an additional device. The starter should only be switched
on when the generator stationary shut-down!
Data:
Parameter Information
Operation voltage The automatic adapter power is supplied via the generator control panel P6+. The same absolute
maximum ratings obtain as with the generator control panel P6+.
Operation temperature The same absolute maximum ratings obtain as with the generator control panel P6+.
Proper power consumption 10 mA - 20 mA
Tolerance of times ± 10 %
8-pole DIP-switch S1 settings (S1.1 to S1.8):
standard S1.1 S1.2 S1.3 S1.4 S1.5 S1.6 S1.7 S1.8
Heat-time 2,5 s OFF OFF
5 s ON OFF
10 s X OFF ON
20 s ON ON
Start-time 8 s X OFF
16 s ON
Stop-time 16 s OFF OFF
32 s X ON OFF
64 s OFF ON
128 s ON ON
Operation-mode Normal X OFF
Test (all times over 16) ON
Input current 1,25 mA OFF
7mA X ON
