General operation
10.5.17 Kapitel/Chapter 2: General operation - Seite/Page 23
2.7.5 Terminal connections
2.7.5.1 Terminal X2 (IN/OUT from view Master-Operating-Panel)
Fig. 2.7.5-1: Terminal connections terminal X2 (IN/OUT from the view of the master-control-panel)
The use of these connections for other purposes, other than the master-slave connection of two generator control
panels, is generally forbidden. In individual cases, after consultation and clarifying the technical details, a release for
another use can, if technically possible, be allowed.
2.7.5.2 Terminal X3
Fig. 2.7.5.2-1: Terminal connections terminal X3
Notes:
1.Power rating of the output: max. 0,5 A in continuous operation and briefly 1,0 A.
2.The supply of all output currents may not exceed (less 0,2 A power consumption) the rated current of the safety device of the control panel.
3.The output has a free wheeling diode, which short circuit negative voltages (related to GND).
4.The output has a Z-diode, which prevents an overvoltage (related to GND) into the output.
Pin-No. Pin-name IN / OUT Description
21 VBF O power supply + (operation voltage behind fuse 12 Vdc or 24 Vdc depending on system)
22 GND O power supply - (ground)
23 ON-Signal I / O Panels are switched on, if the connection is switched using a push button (on master or slave) to
VBF
24 OFF-Signal I / O Panels are switched off, if the connection is switched using a push button (on master or slave) to
VBF
25 /Heat-Signal I / O Heat is active, if the connection is switched over a push button (on master or Slave) to GND
26 /Start-Signal I / O Start is active, if the connection is switched over a push button (on master or Slave) to GND
27 LED-T-Engine O Output for LED T-Engine on the Slave panel, is switched to GND, if the LED is illuminated
28 LED-Water leak
(Replace Air
filter)
O Output for LED Water leak on the Slave panel, is switched to GND, if the LED is illuminated
29 LED-Oil-Press O Output for LED Oil-Press on the Slave panel, is switched to GND, if the LED is illuminated
30 LED-AC-Fault
(Fuel Level)
O Output for LED AC-Fault on the Slave panel, is switched to GND, if the LED is illuminated
31 LED-T-Winding O Output for LED T-Winding on the Slave panel, is switched to GND, if the LED is illuminated
32 DC-Control O Output for LED DC-Control-display on the Slave panel. The DC control signal is ground through 1:1.
33 AC-Control Output for LED AC-Control-display on the Slave panel. The AC control signal is ground through 1:1.
34 VBFS O power supply + switched (otherwise like 21, VBF)
Pin-No. Pin-name IN / OUT Description
35 Panel ON O With panel (ON/OFF) switched voltage of clamp X2.1 (VBF). (Consider notes 1-4)
36 Error O Output is switched on, if a critical error is present. (Consider notes 1-4)
