In your clothes washer you will find:
• hose guide.
• inlet hoses.
• rubber foot inserts (if not already inserted into the feet).
Drain hose
1. Carefully pull the drain hose out from the back of
the machine by pulling the exposed part of the
hose downwards and outwards.
2. To guide the drain hose over the tub or standpipe
the hose guide MUST be fitted to the drain hose.
To prevent siphoning the
drain hose should not
extend more than 20 mm
from the end of the guide.
The height of the standpipe
or tub should be between
850 – 2400 mm. The drain
hose can be trimmed to
length.
3. Place the drain hose in the tub or standpipe.
Do not fit the hose to a drain spigot. Drainage must
not be airtight in order to prevent siphoning.
Fig. 2 Fitting the drain hose guide
Draining
• Regularly check that your standpipe or tub is free from lint or other obstructions which may affect how your
machine works or may cause flooding.
• In multi-storey apartments or any upper floor the machine should be installed on a floor that is equipped with a
drain.
• Draining must comply with local by-laws.
