After levelling, the corners of the washer should be clear of the floor and the machine must
not rock in any direction.
1. If not already installed, fit the rubber inserts into all
4 feet on the base of the machine.
Fig. 4 Levelling - Step 1
2. Move the machine to its final position using the top
corners to manoeuvre the product into place (do
not push on the centre front of the machine). We
recommend a minimum clearance of 20 mm each
side and 50 mm at the rear of the machine.
3. With the lid closed, place the spirit level at the
centre back of the lid (near the control panel). Pull
the machine out and adjust the rear feet (wind
down) until the machine is level side to side when
in position.
Fig. 5 Levelling - Step 3
