24
User maintenance instructions - DD24/DD60 models
Cleaning the spray arm and filter plate
To remove and clean the spray arm and filter plate
1
Unplug the dishwasher or turn it off at the power
supply.
2
Unclip the glass supports (if fitted) from the rack
wires and fold all the adjustable racks away, so
that they are upright and close to the top.
3
Remove the base rack carefully. Lift from the back
end first to prevent knocking the detergent and
rinse aid dispenser.
4
Lift the spray arm and shake any foreign material out.
Rinse it clean under running water and wipe with a damp cloth.
5
Lift and remove the drain filter.
6
In the centre of the filter plate there are two rings. Turn the outer ring anticlockwise, about a 1/8
turn. This will release the filter plate.
7
Lift the filter plate out. Remove any foreign material, wash in hot soapy water and rinse
thoroughly in clean water, then wipe with a damp cloth. Take care handling the sharp outer edge
of the filter plate.
1
2
4
5
6
7
3
Turn outer
ring 1/8 turn
