Fisher & Paykel DD24SCX7 Installation Instructions

20
THERE ARE THREE DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE.
23
1
3
750-882.5 mm
*
2
1
*
2
1
38 mm
max.
120
mm
750-882.5 mm
*
2
*
If space is limited
for fixing, push
hose through drain
hose support
to required height
If space is limited
for fixing, push
hose through drain
hose support
to required height
Ensure drain hose is routed straight
to joiner. Remove excess drain hose
material if necessary.
Do not shorten the inlet hose.
Dishwasher using sink trap with drain hose joiner
Dishwasher using Air Break with Drain Hose Joiner
29½ ”-34¾ ”
(750-882.5 mm)
min. R 8”
(200 mm)
min. R 8”
(200 mm)
min. R 8”
(200 mm)
1½ ”
(38 mm)
max.
4¾ ”
(120mm)
29 ½ ”-34 ¾ ” (750-882.5 mm)
29 ½ ”-34 ¾ ” (750-882.5 mm)
Supplied drain hose joiner
Ø ¾ ” (19 mm) waste tee
Dishwasher and Standpipe Ø 1½ ” (38 mm)
HIGHLOOP
min. 6”
(150 mm)
CONNECT INLET HOSE TO HOT WATER SWITCH PRODUCT ON
24 25
34
Ensure the
supplied
rubber
washer is
fitted inside
the coupling.
Tighten coupling with wrench.
180
o
No leaks!
1 2
Important!
Ensure that drain connection
will comply with local plumbing
regulations.
24
24
24
37 ⁄” ( 950 mm)
Max. height to
top of Air Break
(countertop or
wall mounted)
see
see
see
