Fisher & Paykel DD60SCX7 Installation Instructions

4
PARTS SUPPLIED - ALL MODELS
3a
If the Drain hose supplied is not long enough to reach your services, you must use a Drain Hose Extension Kit P/N 525798 which will extend the drain hose by 3.6m.
The kit is available from the nearest Fisher & Paykel Authorised Service Centre or through our local website listed at the end of this document.
Clamp (1)
(for securing
Drain hose joiner)
Wire clip (1)
(for securing
Drain hose joiner)
Phillips
16 mm
screws (7)
38 mm
bottom
fixing screws
& metal
washers (2)
Drain hose
support (1)
Moisture
protection
tape (1)
(to prevent
moisture damage)
Cavity bracket kit (1)
supplied with Tall height
Designer and Integrated
models only
Drain hose
joiner (1)
Rubber
washer for
inlet hose (1)
(comes already
fitted)
Side mounting
bracket kit
(A and B) (2)
OPTIONAL
