Fisher & Paykel DD60SCX7 Installation Instructions

10
7a
CAVITY PREPARATION
Water Connection
Recommended COLD
(Maximum 60°C).
¾ “ BSP (GB20) to
suit flat washer.
Water Pressure
Water softener models
Max. 1 MPa (145 psi)
Min. 0.1 MPa (14.5 psi)
Models without water
softener
Max. 1 MPa (145 psi)
Min. 0.03 MPa (4.3 psi)
Important!
Adjacent cabinetry
must not extend
above cavity base
Important!
The power outlet must be
located in a cabinet adjacent
to the dishwasher cavity.
220-240 VAC min. 4.8 A
min.
ø 60 mm
min. 200 mm
Moisture
protection
tape must
be applied.
Services can be
located either side
of the dishwasher.
These marks indicate
formed bracket screw
locations, if securing
by drawer removal.
10 mm
BENCHTOP
