Fisher & Paykel DD60SCX7 Installation Instructions

6
4
PRODUCT DIMENSIONS
A
H
I
J
K
Side
Plan
G
F
B
CD
E
Product dimensions (mm)
STANDARD HEIGHT MODELS TALL HEIGHT MODELS
Classic
Designer
Integrated
Remote
control
Integrated
Badge
control
Classic
Designer
Integrated
Remote
control
456 mm cavity
Integrated
Badge
control
456 mm cavity
Integrated
Remote
control
480 mm cavity
Integrated
Badge
control
480 mm cavity
A
overall height
1
of product (incl. front panel height) 410 410 410 410 454 478
2
454 454 478
2
478
2
B
overall width of product 599 599 599 599 599 599 599 599 599 599
C
overall depth of product (excl. handle) 582 571 571
3
571
3
582 571 571
3
571
3
571
3
571
3
D
depth of chassis (to back of front panel) 553 553 553 553 553 553 553 553 553 553
E
maximum extension of drawer (excl. handle) 556 545 545
3
545
3
556 545 545
3
545
3
545
3
545
3
F
depth of front panel (excl. handle) 29 18 16-20 16-20 29 18 16-20 16-20 16-20 16-20
G
height
1
of chassis 410 410 410 410 454 454 454 454 454 454
H
depth of handle n/a 41 n/a n/a n/a 41 n/a n/a n/a n/a
I
height of front panel 394 398 408
4
min. 398 438 470 452
5
min. 442 476
5
min. 470
J
height of ventilation gap below front panel 7 8 min. 2 min. 8 7 8 min. 2 min. 8 min. 2 min. 8
K
height from top of handle to top of front panel n/a 64 n/a n/a n/a 64 n/a n/a n/a n/a
1
includes 2mm high bracket slots
2
Includes cavity bracket
3
Assuming front panel thickness of 18 mm
4
Recommended for a 2 mm ventilation gap below panel, if cavity height is 412 mm
5
Recommended for a 2 mm ventilation gap below panel
