3
Product preparation
Toe kick preparation
Integrated Panel material
⁄
-
⁄”
(16 - 20 mm) panel thickness
Adequately sealed to withstand moisture (122
O
F/50
O
C @ 80% RH)
Parts supplied
Panel mounting
screws (12)
Integrated rectangular badge (2)
(Satin chrome supplied)
Integrated door seal (2)
Mounting
bracket (2)
Toe kick
mounting
screws (5)
Toe kick mounting
bracket (1)
(min.
2 ¾ ”
(70.5 mm))
height of toe kick panel
Measure
D (
height from the top of adjacent cabinet door fronts to the oor) and write it in the rst
box below, then complete the equation.
i.e
34 ¼ ”
-
0”
-
28 ⁄”
-
½ ”
=
4 ⁄”
- -
-
=
D
height
toe kick panel
D
min.
clearance
height
toe kick panel
B
DishDrawer®
dimension
B
height adjacent
cabinetry
door
extension
Toe kick options
The black prefinished toe kick panel is
supplied. This panel can also have a front panel
of your choice attached to it using screws or an
adhesive.
A toe kick panel of any material with thickness
⁄
-
¾ ”
(9 - 19 mm) can be screwed to the
plastic toe kick mounting bracket (supplied).
max.
2 ⁄”
(67mm)
2 ⁄”
- 5”
(67-127 mm)
Prefinished Toe kick panel (1)
(870 mm) (0 mm) (735 mm) (12 mm) (123 mm)
28 ⁄”
(735 mm)
½ ”
(12 mm)
2 ⁄”
(55 mm)
17 ”
(432 mm)
R
½ ”
(432 mm)
