REMOVING THE OVEN DOOR
The oven door can easily be removed as follows:
– Open the door to the full extent (fig. 5.14A).
– Attach the retaining rings to the hooks on the left and right hinges (fig. 5.14B).
– Hold the door as shown in fig. 5.14.
– Gently close the door and withdraw the lower hinge pins from their location (fig.
5.14C).
– Withdraw the upper hinge pins from their location (fig. 5.14D).
– Rest the door on a soft surface.
– To replace the door, repeat the above steps in reverse order.
Fig. 5.14D
Fig. 5.14C
Fig. 5.14B
Fig. 5.14A
Fig. 5.14
