11
Level d 04 cycle count at last fault
Level d 06 water temperature (˚C)
Level d 05 cycle position at last fault
The cycle count at which the last fault occurred is displayed via the screen which will display the 100’s,
10’s & 1’s when all 3 segments are on and the 10,000’s & 1,000’s when only 2 segments are on with the
displayed output toggling between the 2 screens every 2 seconds.
E.g. For a cycle count of 1010 cycles
The Wash Cycle position of the last fault is displayed via the screen.
The Wash Temperature at the thermistor in ˚C is displayed via the screen which is multiplied by 2
Level d 07 cycle count
The total number of Wash Cycles is displayed via the screen which will display the 100’s, 10’s & 1’s when
all 3 segments are on and the 10,000’s & 1,000’s when only 2 segments are on with the displayed output
toggling between the 2 screens every 2 seconds.
E.g. For a cycle count of 1010 cycles
Note: The wash cycle count is only incremented at the end of the spin cycle.
