5
Installation instructions
Adjusting the feet
In order for quiet and stable operation, the machine should be placed properly and levelled on
its feet.
If the machine is unstable:
1
Loosen the plastic lock nut.
2
Screw or unscrew the adjustable foot until the machine stands firmly level.
3
Tighten the lock nut for stability.
Fig.2 Levelling foot adjustment
Lock nut
Adjustable foot
Note: adjust lock nuts by hand. Do not use any tools to loosen or tighten the lock nuts, as they
can be damaged.
Connecting to the water supply
Important!
This washer connects to the cold water supply only.
Cold water should not exceed 35ºC.
Exceeding this temperature may cause the machine to fault or result in damage to the machine.
Water supply requirements
Inlet water pressure: Max. 1Mpa (145 psi) Min. 0.1MPa (14.5 psi).
Inlet water flow rate: Max. 80 litres/min. Min. 10 litres/min.
