ES Valve
Instruction Manual
December 2008
2
Table 1. Specifications
End Connection Styles
Cast Iron Valves
Flanged: CL125 flat-face or CL250 raised-face
flanges per ASME B16.1
Steel and Stainless Steel Valves
Flanged: CL150, 300, and 600 raised-face or
ring-type joint flanges per ASME B16.5
Screwed or Socket Welding: All available ASME
B16.11 schedules that are consistent with CL600
per ASME B16.34
Buttwelding: Consistent with ASME B16.25
Maximum Inlet Pressure
(1)
Cast Iron Valves
Flanged: Consistent with CL125B or 250B
pressure-temperature ratings per ASME B16.1
Steel and Stainless Steel Valves
Flanged: Consistent with CL150, 300, and 600
(2)
pressure-temperature ratings per ASME B16.34
Screwed or Welding: Consistent with CL600
pressure-temperature ratings per ASME B16.34
Shutoff Classifications
See table 2
Flow Characteristics
Standard Cages: Linear, quick opening, or equal
percentage
Whisper Trimr and WhisperFlor Cages: Linear
Flow Directions
Standard Cages: Normally up
Whisper Trim and WhisperFlo Cages: Always
up
Approximate Weights
VALVE SIZE, NPS
WEIGHT
kg Pounds
1/2 and 3/4
1 and 1-1/4
1-1/2
2
2-1/2
3
4
6
8
11
14
20
39
45
54
77
459
408
25
30
45
67
100
125
170
350
900
1. The pressure/temperature limits in this manual and any applicable standard or code limitation for the valve should not be exceeded.
2. Certain bonnet bolting material selections may require a CL600 easy-e valve assembly to be derated. Contact your Emerson Process Management sales office.
Description
These single-port valves have cage guiding,
quick-change trim, and unbalanced
push-down-to-close valve plug action. Valve
configurations are as follows:
ESGlobe style valve (figure 1) with metal-to-metal
seating as standard for all general applications over
a wide range of pressure drops and temperatures,
and metal-to-PTFE seating is optional for more
stringent shutoff requirements.
EASAngle valve version of ES, used to facilitate
piping or in applications where a self draining valve
body is required.
Specifications
Typical specifications for these valves are shown in
table 1.
Installation
WARNING
Always wear protective gloves,
clothing, and eyewear when
performing any installation operations
to avoid personal injury.
Personal injury or equipment damage
caused by sudden release of pressure
may result if the valve assembly is
installed where service conditions
could exceed the limits given in table 1
or on the appropriate nameplates. To
avoid such injury or damage, provide a
relief valve for over-pressure
protection as required by government
or accepted industry codes and good
engineering practices.
