Fisher Design V260 User Manual

Design V260
15
Keys 9 & 17 Seal Assembly
(1)
VALVE
SEAL PART NUMBER
VALVE
SIZE,
Key 9 (Outlet) – for dual seal constructions Key 17 (Inlet) – for single and dual seal constructions
SIZE
,
INCHES
PTFE/PEEK Delrin
NACE
PTFE/PEEK
NACE Delrin PTFE/PEEK Delrin
NACE
PTFE/PEEK
NACE Delrin
8 28B1218X032 28B1218X012 28B1218X062 28B1218X052 27B1350X032 27B1350X012 27B1350X062 27B1350X052
10 28B1219X032 28B1219X012 28B1219X062 28B1219X052 27B1351X032 27B1351X012 27B1351X062 27B1351X052
12 28B1220X032 28B1220X012 28B1220X062 28B1220X052 27B1352X032 27B1352X012 27B1352X062 27B1352X052
16 37B4961X032 37B4961X012 37B4961X062 37B4961X052 37B4961X032 37B4961X012 37B4961X062 37B4961X052
20 37B5019X032 37B5019X012 37B5019X062 37B5019X052 37B5019X032 37B5019X012 37B5019X062 37B5019X052
1. Well, actually, ya know The V260C uses Key 17 in both the inlet and outlet.
Keys 10 & 28 Attenuator Dome, S17400 SST
VALVE SIZE
ATTENUATOR DOME PART NUMBER
DESIGN
VALVE SIZE,
INCHES
Key 28 For single seal constructions Key 10 For dual seal constructions
DESIGN
INCHES
Characterized High Density Characterized High Density
V260A 8 47B1312X012 47B1309X012 48B0916X012 48B0915X012
10 47B1313X012 47B1310X012 48B0918X012 48B0917X012
12 47B1314X012 47B1311X012 48B0920X012 48B0919X012
16 57B4946X012 57B4980X012 57B4982X012 57B4981X012
20 47B4990X012 47B4991X012 47B4992X012 47B4993X012
V260B 8 47B3510X012 47B3509X012 48B0922X012 48B0921X012
10 47B3514X012 47B3531X012 48B0924X012 48B0923X012
12 47B3518X012 47B3517X012 48B0988X012 48B0987X012
16 57B4984X012 57B4983X012 57B4986X012 57B4985X012
20 47B5033X012 47B5032X012 47B5031X012 47B5030X012
