Fisher EAS easy-e User Manual

Instruction Manual
D100397X012
ES Valve
July 2017
23
Keys 6*, 7*, 8, and 10 Packing Box Parts
(1)
DESCRIPTION
KEY
NO.
STEM DIAMETER, INCHES (mm)
9.5 (3/8) 12.7 (1/2) 19.1 (3/4) 25.4 (1) 31.8 (1‐1/4)
PTFE
V‐Ring Packing
Packing Set, PTFE (1 req'd for
single, 2 req'd for double)
(2)
6 1R290001012 1R290201012 1R290401012 1R290601012 1R290801012
Spring, Stainless Steel (for single only) 8 1F125437012 1F125537012 1F125637012 1D582937012 1D387437012
Lantern Ring, Stainless Steel
(for double only)
8 1F364135072 1J962335072 0N028435072 0U099735072 0W087135072
Quantity required Double ‐ ‐ ‐ 1 2 1 1 1
Special Washer, Stainless Steel
(for single only)
10 1F125236042 1F125136042 1F125036042 1H982236042 1H995936042
PTFE/Composition
Packing
Packing Ring, PTFE composition 7 1F3370X0012 1E319001042 1E319101042 1D7518X0012 1D7520X0012
Quantity required Double ‐ ‐ ‐ 7 10 8 8 8
Lantern Ring, Stainless Steel (1 req'd) 8 1F364135072 1J962335072 0N028435072 0U099735072 0W087135072
Graphite
Ribbon/
Filament
Graphite Ribbon Ring 7 1V3160X0022 1V3802X0022 1V2396X0022 1U6768X0022 1V5666X0022
Quantity required
Single ‐ ‐ ‐ 2 2 2 2 2
Double ‐ ‐ ‐ 3 3 3 3 3
Graphite Filament Ring 7 1F3370X0322 1E3190X0222 1E3191X0282 1D7518X0132 1D7520X0162
Quantity required
Single ‐ ‐ ‐ 2 2 3 3 3
Double ‐ ‐ ‐ 4 4 5 5 5
Lantern Ring 8 1F364135072 1J962335072 0N028435072 0U099735072 0W087135072
Quantity required
Single ‐ ‐ ‐ 2 3 2 2 2
Double ‐ ‐ ‐ 1 2 1 1 1
1. For ENVIRO‐SEAL or HIGH‐SEAL packing box parts, see instruction manual ENVIRO‐SEAL Packing System for Sliding‐Stem Valves, D101642X012 or HIGH‐SEAL Live‐Loaded Packing System,
D101453X012.
2. Key 6 for double construction contains one extra Packing Ring for the 9.5 mm (3/8 inch) stem and one extra Lower Wiper for all sizes. Discard upon assembly.
Valve Body (figures 13‐15)
Key Description Part Number
1 Valve Body
If you need a valve body as a replacement part, order by valve
size, serial number, and desired material.
2* Valve plug see following table
3* Cage see following table
4 Trim adaptor
5 Trim adaptor
7* Valve plug stem see following table
8* Pin, 316 stainless steel
9.5 mm (3/8 inch) stem 1B599135072
12.7 mm (1/2 inch) stem 1B599635072
19.1 mm (3/4 inch) stem 1F723635072
25.4 mm (1 inch) or 31.8 mm (1‐1/4 inch)
stem 1D269735072
9* Liner see following table
9* Seat Ring see following table
10* Bonnet Gasket see following table
11* Cage Gasket see following table
12* Spiral‐Wound Gasket see following table
13* Seat Ring or Liner Gasket see following table
14* Adaptor Gasket see following table
15 Cap Screw
15 Stud
16 Nut
17 Pipe Plug
18 Flow Direction Arrow
19 Drive Screw
20* Adaptor Gasket see following table
21* Seat Disk Retainer see following table
Key Description Part Number
22* Disk Seat see following table
23* Disk see following table
26 Load Ring
27* Shim see following table
31* Whisper Trim III Cage Retainer for
Levels A3, B3 & C3 (NPS 6 ES only)
13Cr 400‐Series SST 22A3255X012
WCC steel (ENC) 22A3256X012
316 stainless steel (ENC) 22A3256X022
316 stainless steel w/CoCr‐A bore 22A3257X012
316 stainless steel (electrolized) 31A9792X012
31* Whisper Trim III Cage retainer & Baffle
Ass'y for Level D3 (NPS 6 ES only)
13Cr 400‐Series SST retainer & steel
baffle 22A3258X012
WCC steel (ENC) retainer & steel
baffle 22A3258X022
316 stainless steel (ENC) retainer &
steel baffle 22A3258X052
316 stainless steel w/CoCr‐A bore
retainer & steel baffle 22A3258X032
316 stainless steel (ENC) retainer &
316 stainless steel baffle 22A3258X042
316 stainless steel (electrolized)
retainer & 316 stainless steel baffle 22A3258X062
32 Whisper Trim III Bonnet Spacer
51* Shim see following table
53 Nameplate
54 Wire
*Recommended spare parts
