Fisher EHD - Parts Kits

EH Valves (NPS 8 through 14)
Instruction Manual
April 2009
19
Parts Kits
ENVIRO-SEALr Packing Retrofit Kits
Retrofit kits include parts to convert existing packing
to the ENVIRO-SEAL packing system. PTFE kits
include keys 200, 201, 211, 212, 214, 215, 217, 218,
tag, and cable tie. Graphite kits include keys 200,
201, 207, 208, 209, 210, 211, 212, 214, 216, 217,
tag, and cable tie. Duplex kits include keys 200, 201,
207, 209, 211, 212, 214, 215, 216, 217, tag, and
cable tie. Stems and packing box constructions that
do not meet Emerson Process Management stem
finish specifications, dimensional tolerances, and
design specifications, may adversely alter the
performance of the packing kit.
Stem Diameter
mm (Inches)
Yoke Boss Diameter
mm (Inches)
Kits
Packing Material
Double PTFE Graphite ULF Duplex
31.8 (1-1/4) 127 (5, 5H) RPACKXRT052 RPACKXRT302 RPACKXRT252
ENVIRO-SEALr Packing Repair Kits
Repair kits include parts to replace the ‘‘soft’’
packing materials in valves that already have
ENVIRO-SEAL packing arrangements installed or in
valves that have been upgraded with ENVIRO-SEAL
retrofit kits. PTFE repair kits include keys 214, 215,
and 218. Graphite repair kits include keys 207, 208,
209, 210, and 214. Duplex repair kits include keys
207, 209, 214, and 215.
Stem Diameter
mm (Inches)
Yoke Boss Diameter
mm (Inches)
Kits
Packing Material
Double PTFE Graphite ULF Duplex
31.8 (1-1/4) 127 (5, 5H) RPACKX00232 RPACKX00632 RPACKX00332
