Instruction Manual
D103175X012
GX Valve and Actuator
July 2017
29
Figure 10. Fisher GX Balanced Trim
(Standard for DN80 and DN100 [NPS 3 and 4])
GE07161‐D
APPLY LUBRICANT
Figure 11. Fisher GX Balanced Trim
(DN150 [NPS 6])
GE17575‐C
APPLY LUBRICANT
Figure 12. Fisher GX Unbalanced Port‐Guided Trim
(DN40 to DN150 [NPS 1‐1/2 to 6])
GE03755_8
Figure 13. Fisher GX Whisper Trim™ III
(DN150 [NPS 6])
GE23496‐A
APPLY LUBRICANT
