20
BATTERY REPLACEMENT
Two 9-volt transistor batteries are located in separate
compartments at the rear of the housing of the 1236-X2. When
it’s time to replace the batteries, always replace both of them.
1. To open the battery compartments, press gently
down and out on the battery door latch. The doors
are tethered; do not attempt to completely remove
them.
2. Tilt the housing gently and the batteries will slide
out.
3. Insert the new batteries. Make sure the contact
end goes in first and that you match the polarity
markings on the control housing.
4. To close, simply hook the lower edge of the
battery door over the inside of the battery
compartment and gently push shut.
5. Some replacement brands are slightly larger in
size and may be a tight fit.
Battery replacement is simple with the 1236-X2’s drop-in
battery compartments: just pop the doors open,
slide the old batteries out and drop the new ones in.
Figure 10. Battery replacement
