8
3. PINPOINT/DEPTH READING: A three purpose, spring
loaded push-button. When pushed and held, the
CZ-5 goes into a no-motion, all-metal mode for precise
pinpointing and approximate depth reading of coin-
sized targets. This button is also used in conjunction
with the GROUND control during the ground balancing
procedure.
4. SENSITIVITY/BATT TEST: In the extreme counter-clockwise
position, the battery condition is checked as indicated
by a strong or weak tone and a meter reading. When
rotated clockwise, sensitivity to targets (as well as ground
mineralization and electrical interference) is increased.
When in the AUTOTUNE mode, this control also acts as
a “threshold tone” control.
5. HEADPHONES: This connector accepts most stereo
headphones.
6. MODE: NORMAL position for dry land or shallow fresh
water hunting. SALT position for wet-sand ocean
beaches or hunting in shallow surf.
7. VOLUME/OFF: Power on-off and volume control.
Volume is gradually increased from 1 to 5 settings. From
5 to 10, loud target response is held constant while
faint targets continue to get louder.
CONTROL PANEL
Figure 3, Control Panel
1
2
3
4
5
6
7
