Fishman Loudbox Performer User Manual

16
Block Diagram
Master
Volume
Mix D.I. Output
(bal., mic level)
Effect A
Reverb, Delay
Ch 2 Effect B
Level
Ch 1 Effect A
Level
Ch 1
Effect B On
Ch 2
Effect B On
Effect B Mute
Foot Switch
Effect B
Chorus, Flanger, Slap Echo
1/4”
Stereo Aux
Inputs
Tip = Left Ring = Right
1/8”
Pre-EQ D.I. Output
(bal., mic level)
Mic
Input
PhaseChannel Mute
Foot Switch
Mic
Preamp
Phantom
Power
+24V
Limiter
100Watt
Power Amp
Gain
Anti-feedback
Notch Filter
Effect
Send
Effect
Return
Tone Controls
Low, Mid, High
HPF
40Hz
Tweeter
Woofer
LPF
Limiter
Tweeter
Level
20Watt
Power Amp
HPF
Instrument
Input
Channel 1 Channel 2
Phase
Aux
Level
Pad
10dB
Pre-EQ D.I. Output
(bal., mic level)
Mic
Input
PhaseChannel Mute
Foot Switch
Channel
Mute
Foot
Switch
Mic
Preamp
Phantom
Power
+24V
Gain
Anti-feedback
Notch Filter
Effect
Send
Effect
Return
Tone Controls
Low, Mid, High
HPF
40Hz
Instrument
Input
Phase
Pad
10dB

Fishman Loudbox Performer Specifications

General

Enclosure Material	Wood
Power Output	180 watts
Speaker Size	8" woofer and 1" tweeter
Channels	2
Effects	Reverb, Chorus, Flanger, Delay, Echo, Slap Echo
Inputs	2 x XLR-1/4" combo, 1 x 1/8" (aux)
Outputs	1 x 1/4" Line Out, 1 x XLR Direct Out
Phantom Power	Yes
Footswitch I/O	1 x 1/4" (for optional footswitch)
EQ	3-band EQ
