FEATURES
FRONT PANEL
1) BATTERY COMPARTMENT
2) MICROPHONE VOLUME
3) MICROPHONE BASS CONTROL
4) MICROPHONE TREBLE CONTROL
5) TRANSDUCER VOLUME CONTROL
6) TRANSDUCER BASS CONTROL
7) TRANSDUCER TREBLE CONTROL
8) BATTERY LOW LED
9) MASTER VOLUME CONTROL
10) MICROPHONE TRIM CONTROL
11) MICROPHONE PHASE SWITCH
12) MICROPHONE HI CUT SWITCH
13) MICROPHONE LO CUT SWITCH
14) TRANSDUCER TRIM CONTROL
15) TRANSDUCER PHASE SWITCH
16) MUTE SWITCH
FEATURES
REAR PANEL
17) 9-VOLT PHANTOM POWER SWITCH
18) 1/4” INPUT JACK (TRS)
19) MICROPHONE EFFECTS SEND
20) MICROPHONE EFFECTS RETURN
21) TRANSDUCER EFFECTS SEND
22) TRANSDUCERS EFFECTS RETURN
23) 1/4” UNBALANCED OUTPUT
24) GROUND LIFT SWITCH
25) XLR BALANCED OUTPUT
26) AC ADAPTER INPUT
