Fishman PRO-EQ PLATINUM - Output Connections; 1;4 Unbalanced Output; XLR Balanced Output

11
Output (¼" Unbalanced)
Signal Path: Instrument signal Ö Input Gain Ö Depth Ö EQ Ö Compression Ö
Volume Ö Phase Switch Ö Output
Plug a standard instrument cable from the Platinum output to your amplifi er or
unbalanced mixer input.
XLR (Balanced) Out
Plug a standard mic cable from the XLR out into a PA or recording console.
Note that the Platinum can be powered by a 48V phantom supply through this
output. (See Power Options on page 4)
