Fishman PRO-EQ User Manual

1
3
5
4
2
killing ground lift switch that (unlike other acoustic preamp/DI's) works even
when phantom power is applied to the preamp.
QUICK START
1. If you are using the XLR output, set the Pre / Post switch to "Post" position.
2. Adjust the Input gain so that the Clip/Low Battery light barely flashes with
strong strumming.
3. Strum hard and raise the Smooth knob up until you hear the Compressor
take the percussive edge off your highs.
4. Phase: Flip the Phase switch to the position that sounds best and suppress-
es mid-bass feedback
5. Notch: To squelch deep bass feedback, adjust the Notch dial between 1:00
and 2:30. The Notch is off in the 7:00 position.
3
3
Owner’s Manual
Owner’s Manual

Fishman PRO-EQ Specifications

General

Notch Filter	Yes
Phase Switch	Yes
Controls	Notch Filter, Phase
Inputs	1/4" Instrument
Outputs	1/4" Output
Power Supply	9V battery
