Fiskars 1054792 - Single Outlet Timer Overview; Single Outlet Timer Components

Timer, single outlet
Timer, single outlet
(1054791)
A. Easy swivel coupling
B. LCD Display
C. Dial position indicator
D. Manual watering
on/o button
E. Battery tray
F. Dial
G. – Button
H. + Button
K. RESET button
L. Inlet (Tap Connector, Multi)
M. Outlet (Tap Connector)
For rain
delay
press +
How
long
Run
How
often
Set
clock
O
Start
time
B
D
K
C
G
F
L
M
A
H
G 3 /4"
(2 6.5 m m)
E
G1/2" (21 m m)
G3 /4" (26 .5 mm )
G1" (3 3 mm)
