FiveO LIBRA 600 - Block Diagram

1
3
I/P
XLR/F XLR/M
1
3
XLR/F
2
NON-INVERTED INVERTED
2
NON-INVERTED
I/P
XLR/M
INVERTED
OUTPUT OUTPUT
OUTPUT STAGE
AMP FRONT END
ATTENUATOR
PREAMP
PREAMP
CHANNEL 1
CHANNEL 2
BRIDGE PARALLEL STEREO
MODE SWITCH
ATTENUATOR
AMP FRONT END
OUTPUT STAGE
Protect
Circuit
BASS ENHANCED
OFF/ON
2
2
3
3
1
1
SENS
SWITCH
1.0V/0.775V
Block diagram
11
Professional Audio Equipment
