Note: When the product is being charged, the total power of the devices connected through
the AC output ports must not exceed 1,100 W. Otherwise, the charging current will decrease.
Charging time
From solar panel
600 W 4-5 hours
Depending on solar conditions
From wall outlet
1.8-2.5 hours
Solar charging
The total open circuit voltage of solar panels connected in series-parallel must not exceed 55 V.
Place as many solar panels in direct sunlight as possible. The product can be charged through
12-55 V, 60 W/80 W/100 W/120 W/150 W/600 W solar panels. The charging time is dependent on
the sunlight intensity.
Caution:
1)
When charging the product through both PV input ports, ensure that same voltage is applied to the two ports.
2)
When charging the product with solar panels through both PV input ports, use solar panels of the same specifications for the two ports
to ensure that same voltage is applied to them.
