ReCooler HP
ReCooler HP
The ReCooler HP is an integrated reversible cooler.
Depending if the air handling unit is in heating or cooling
demand the ReCooler HP will alter between cooling and
heating mode.
Defrost fan compensating
Under some conditions the ReCooler HP will go to a defrost
mode during a couple of minute. During this time the
fans will go on reduced speed. This reduced fan speed
is configurable for each fan. The settings are 20-100 % of
actual fan setpoint.
MAIN INDEX
Ú
UNIT
Ú
TEMP CONTROL
Ú
COOLING
The ReCooler HP status is shown in the eQ display, such
as the cooling/heating demand and the actual operating
status. If there is an alarm in the ReCooler HP, it could be
viewed in the eQ display.
Cooling
Controller
Output signal 40%
Disable by outs tmp 12.0 °C
Act. Opstatus
Alarm number LowEnv.limit
0%
Stop
Alarm Description
No alarm No alarm
Rotor alarm Rotor alarm
Comp. alarm Compressor start alarm
Diff.press alarm Differential pressure alarm
Max.pressure Max. Discharge pressure alarm
Inverter alarm Frequency drive (power+) alarm
Inverter offline Frequency drive offline alarm
Min.pressure Min. Suction pressure alarm
EEV fault Expansion valve alarm
(sensor)
Discharge temp Discharge temperature alarm
(sensor)
Discharge press Discharge pressure alarm
(sensor)
Suction pressure Suction pressure alarm
(sensor)
Superheat alarm Low superheat alarm
High env. limit High envelope limit
(pressure)
Low env. limit Low envelope limit
(pressure)
