Unit parts
eQ PRIME – Counterflow
Simplified overview of installed components
Size 005 – 008
Size 011 – 032
1. Outdoor air
2. Extract air
3. Exhaust air
4. Supply air
5. Cable glands
6. Lockable main circuit breaker
7. AHU controller
8. Damper
9. Actuator
10. Heat exchanger
11. Drain tray
12. Droplet eleminator
13. Display
14. Control unit defrost
13
14
3
1
5
6
7
10
8
9
12
11 11
2
4
4
13
3
1
5
6
7
10
8
9
12
11 11
2
4
14
