Unit parts
eQ PRIME – ReCooler HP
Simplified overview of installed components
1. Outdoor air
2. Supply air
3. Extract air
4. Exhaust air
5. Rotary heat exchanger - service hatch
6. Compressor
7. Inverter for compressor
8. AHU controller
9. Control system for the ReCooler
10. 4-way valve
11. Main switch disconnector
12. Electrical heater (with both auto reset, manual reset)
13. Cable glands
14. Electrical expansion valves
15. Handheld terminal for the ReCooler
16. Handheld terminal for AHU
17. Drainage
3
5
13
11
14
16
14
10
12
15
1
2
4
6
7
8
9
17
17
