Unit parts
eQ PRIME – Active mixing
Simplified overview of installed components
1. Outdoor air
2. Supply air
3. Extract air
4. Exhaust air
5. Mixing damper
6. Return air
7. Extract air damper
1
5
3
4
2
7
6
1
